** THIS ITEM IS SOLD BY THE METRE
| SKU |
Part No. | Dia | D | W1 | W2 |
|---|---|---|---|---|---|
| mm | mm | mm | mm | ||
| 286-310-1 |
C6XC818206 | 6 | 18 | 7.8 | 22.2 |
| 286-310-2 |
C6XC818207 | 7 | 21 | 9.1 | 25.9 |
| 286-310-3 |
C6XC818208 | 8 | 24 | 10.4 | 29.6 |
| 286-310-4 |
C6XC818210 | 10 | 30 | 13 | 37 |
| 286-310-5 |
C6XC818213 | 13 | 39 | 16.9 | 48.1 |
| 286-310-6 |
C6XC818216 | 16 | 48 | 20.8 | 59.2 |
| SKU | Chain Dia | W.L.L. | M.B.F. | Tolerance | Weight |
|---|---|---|---|---|---|
| mm | t | kN | mm | kgs/m | |
| 286-310-1 | 6 | 0.9 | 36 | +/- 0.5 | 0.8 |
| 286-310-2 | 7 | 1.25 | 50 | +/- 0.6 | 1.15 |
| 286-310-3 | 8 | 1.6 | 63 | +/- 0.7 | 1.3 |
| 286-310-4 | 10 | 2.5 | 98 | +/- 0.9 | 2.14 |
| 286-310-5 | 13 | 4.25 | 170 | +/- 1.2 | 3.65 |
| 286-310-6 | 16 | 6.3 | 248 | +/- 1.4 | 7.6 |
