Tiger Combined Chain Block & Geared Travel Trolley Model CCBTGS, 0.5t Capacity Beam Width 80-128mm

• 0.5t SWL Capacity, to suit a beam width range of 80-128mm (ref 231-1) with a plain powder coated finish
• The CCBTGS geared trolley range is from 0.5t to 30.0t safe working load
• Twin bar or single bar trolley options possible
• The unit can be chained to any height of lift to meet your exact requirements

• Ideal for locations where headroom is limited
• Extended beam width available
• Tiger trolley wheels are specially designed with a convex profile eliminating potential point loading
• The wheels run on sealed bearings for smoother rolling with less effort and maintenance
• The anti-drop plates design ensures extra safety, and also prevents damage to the wheels when contacting end rail stoppers
• Chain carrier available

• Geared and plain trolley versions available
• The 5:1 factor of safety allows for use with manual or powered hoists
• Operating temperature of -30°C to +50°C (temperature range of -50°C to +50°C available as an option)
• Corrosion or Spark Resistant versions also available

Certification

Each unit comes fully certified with a test certificate or an EC Declaration of Conformity stating compliance with the essential health and safety requirements of the Machinery Directive 2006/42/EC.

Due to our policy of continual product development, dimensions, weights and specifications may change without prior notice. Please check with the sales team when ordering.



.	Product Code	Capacity (tonne)	D – Track width				Dimensions (mm)							Min. curve radius (m)	Net Weight (kg) @ std HOL
			Range 1 (mm)	Range 2 (mm)	Range 3 (mm)	Minimum Range 1 & Range 2 with optional locking device (mm)	A	B	C	H	F	G	L
Single Bar Trolleys	CCBTGS-0050	0.5	80-128	80-203	158-310	90	195	180	106	310	20	64	79	0.8	20
	CCBTGS-0100	1	80-128	80-203	160-310	90	213	180	113	340	20	71	82	1	23.5
	CCBTGS-0200	2	112-154	112-230	218-310	125	236	195	136	420	25	80	94	1.3	37.5
	CCBTGS-0300	3	111-153	111-230	217-310	111	275	198	146	504	25	97	126	1.5	53.5
Twin Bar Trolleys	CCBTGT-030T	3	105-153	105-230	207-310	–	320	194	142	460	30	110	132	1.5	58.5
	CCBTGT-0500	5	126-194	126-305	–	–	352	218	166	545	28	131	143	1.5	74.5
	CCBTGT-0600	6	126-194	–	–	–	352	218	166	587	28	131	143	2	93
	CCBTGT-1000	10	125-320	–	–	230	394	282	243	660	40	117	119	1.5	144
	CCBTGT-1500	15	150-320	–	–	150	509	342	276	827	42	182	174	2.7	290
	CCBTGT-2000	20	125-320	–	–	190	754	284	243	950	40	117	119	6	321
	CCBTGT-3000	30	150-320	–	–	155	1009	339	270	1145	42	182	174	6	621
	CCBTGT-3500	35	150-320	–	–	165	1009	335	274	1145	32	182	174	6	651

Download - Technical-sheet-Combi-202409.pdf
